Computer connection

16 computers, with a maximum of 256 cascaded switches

port connector

USB &VGA

Control port type

USB &VGA

Computer selection

Screen menu, hotkeys, buttons

Hotkey

Provide multiple hotkeys（Scroll-Lock / Caps-Lock /Num-Lock / KVM OSD)

 Display screen

Size

17.3" TFT  LED

Resolution

1920*1080 @ 60HZ

Maximum Color

16.7M

Brightness

300nits

Contrast ratio

700 ：1

Display visible surface type / pixel pitch

380*215 16：9  /  0.198 x 0.198 mm

Keyboard/Mouse

104-key notebook keyboard Touchpad

Power supply

Supports dual power sources: AC 100-240V~50/60Hz or a 12V 3.33A power adapter. The device comes with a built-in power supply by default.

Actual power consumption of the entire unit

18W

Material and Craftsmanship

High-strength, corrosion-resistant electrolytic plate

Exterior color

Black high-temperature spray painting with spot application (customizable for other materials)

Size ( L x W x H )

480mm*475mm*44mm；

Travel of guide rail

45MM

Overall open height

335MM

Product weight

Net weight: 10.75 kg; Gross weight: 16.9 kg

Install the cabinet

600-1040mm（Standard hanging hook length: 400 mm; 650 mm/750 mm available for customization. 600 mm cabinet with 90-degree elbow line can be customized.

Storage temperature

-20℃~70℃

Operating temperature

0℃~60℃

Humidity

0%-80%RH
